DB9 Assemblies

TECHNICAL PARAMETERS

—Temperature Range

    Fixed Application : PVC: -20℃~70℃

    During the Installation : PVC : -5℃~70℃

—Minimum Bending Radius

    Fixed Application : 10D(D=cable diameter)

    During the Installation : 15D(D=cable diameter)

CABLE CONSTRUCTION

Conductor:

Fine stranded bare copper wire

Insulation:

PVC

Shielded:

AL/Mylar screen(AL) or AL/Mylar screen and tinned copper(AL+braid)

Jacket:

PVC

Color:

Grey

Assembly with both ends of DB9 connectors

PROPERTIES

Cable flame resistance according to IEC60332-1

Have excellent performance of resistant to external EMI,especially for double shielded

Long service life

Flexible use,can change equipments easily

Provide a variety of length
