Cabling Case | Zhaolong Integrated Cabling System Assists Shanghai Jiushi International Equestrian Center

Views: 27     Author: Zhaolong Interconnect     Publish Time: 2024-06-14      Origin: Site

Shanghai Jiushi International Equestrian Center, Leading the New Development of Chinese Equestrianism

As the first Chinese permanent professional competition venue that meets the standards of top international equestrian events, the Shanghai International Equestrian Center is divided into four areas —— "International Horse Culture and Art Center", "International Equestrian Academy", "International Equestrian Medical and Welfare Center" and "Knight Club". The project covers an area of 3.32 hectares and has a total construction area of about 85,000 square meters. Its main building not only covers competition facilities such as competition venues, warm-up venues, training grounds and high-standard stables, but also includes about 5,000 spectator seats, VIP spectators stands, sky boxes and other top viewing facilities.


In a modern equestrian center, a unique and vibrant large and medium-sized sports venue, various advanced technologies and facilities are closely interwoven to build an efficient, convenient and intelligent environment.  Just like the precision and coordination demonstrated by equestrian sports themselves, the integrated wiring system, as an important thread in the operation of the venue, carries the key mission of information transmission and interaction. It is like an invisible "bond" that closely connects the various areas and functions in the equestrian center, ensuring smooth signal transmission, and laying a solid foundation for the wonderful presentation of equestrian competitions, the orderly development of daily operations, and the ultimate experience of the audience of equestrian competition.


Based on the principle of meeting design requirements and being moderately ahead of the times, and considering the different functional areas and application requirements of the Shanghai International Equestrian Center, Zhaolong recommends the use of Zhaolong S series ClassEA and ClassE solutions.


图6

图5

图8



Advantages of Zhaolong Integrated Cabling System

  • Safety:

During the 2024 Shanghai Longines Global Equestrian Championship, more than 22,000 people watched the game. Given that the equestrian center has a large number of reception personnel and transient population in a very short time, the safety of life and property in the venue is of vital importance. As a building product in the venue, the integrated cabling system needs to pay special attention to its safety and environmental protection performance.


Zhaolong S series integrated wiring products use LSZH sheaths for copper cables and optical cables, with their flame retardancy, smoke density, and halogen all meeting the IEC standard test requirements. In the event of a fire, these products can effectively reduce smoke concentration and toxic gas emissions, thus protecting the lives and property of the staff at the equestrian center.


图3


  • Reliability:

Zhaolong S series Class EA 10G PoE cabling system, its multi-node link system and multi-node channel system have passed the authoritative certification of multiple international authoritative organizations, and can support 1G/2.5G/5G/10GBase-T, which can not only fully meet the voice, data, video, image and other signal transmission needs, but also meet the smooth expansion and upgrade requirements of future networks.


图1


  • Stability:

Zhaolong S series fiber optic wiring connectors use high-precision ceramic ferrules and advanced grinding technology and equipment.  The apex offset of optic connectors of the single-core fiber, optic fiber’s height and curvature radius and other technical parameters all meet the GR-326-CORE and IEC61755 standards, which meet the equestrian center's wiring requirements for large areas, long distances, and stable signal transmission.



In the Future, We Will Continue to Deepen the Informatization Construction of Medium and Large Sports Venues such as Equestrian Centers

Zhaolong's intelligent cabling solutions has continuously penetrated into many industry projects such as government agencies, schools, transportation facilities, hospitals, finance buildings, and smart factories, providing high-speed, secure, and reliable network connections for all walks of life. The Shanghai Jiushi International Equestrian Center project is another successful example of Zhaolong in the field of the cabling of large-scale venue.


From the first international fully-functional and permanent rock climbing competition venue, the rock climbing competition venue for the 19th Asian Games in Hangzhou --- the Shaoxing Keqiao Yangshan Rock Climbing Center in the Zhejiang Province, to the Shanghai Pudong Football Stadium that meets the requirements of the FIFA international A-level competitions, Zhaolong's integrated wiring system has fully demonstrated its efficiency, stability and reliability in the construction of various medium and large venues. The industry-leading advantages and comprehensive functional characteristics demonstrated in many projects strongly indicate that Zhaolong's integrated wiring solution is undoubtedly an ideal choice for various types of venues.


In the future, Zhaolong Interconnect will continue to deepen the informatization construction of medium and large sports venues such as the Equestrian Center, empower China's equestrian sports industry and culture, ensure stable network connections, help achieve efficient information transmission, and promote the construction of smart venues at home and abroad.
